Главная Каталог продукции Toolunited 10 401-01 - Converter, rotationally symmetric E25045525200225

E25045525200225

E25045525200225 E25045525200225 E25045525200225 E25045525200225

E25045525200225

Seco
Артикул: 02416251
В наличии
В корзину
Описание
Характеристики
BD Body diameter
123.698 mm
BLQ Balance quality code
PB
CCFWS Connection code form
10
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
3
CNSC Coolant entry style code
7 - Coolant entry, decentral and axially concentric
COMPC Company code
SO - SECO Tools
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
2000
DCONWS Diameter
50.8 mm
DCP Data chip provision
1 - With data chip
Delivery state valid from
3/14/2020
DIN
SKG05003795
FamilyProducts
E25045525200225
HAND Cutting direction
N - Neutral
ID Technical product number
02416251
Interface codes
J6 / J61
ISO
SKG37C0500$$$$
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
38.1 mm
LF Functional length
57.15 mm
LOC-01 CCFWS Connection code form
10
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
3 Inch with coolant
LOC-01 CZCWS Connection size code
2000
LOC-01 DCONWS Diameter
50.8 mm
LOC-01 ISO
ZYL10S2000****
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL20001035
LOC-02 DCONWS Diameter
50.8 mm
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
SO-FDA200022N0
LOC-03 CCFMS Connection code form
37
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0500
LOC-03 ISO
SKG37C0500$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG05003795
LSCX Clamping length maximum
23.876 mm
Name Identifying order number
E25045525200225
OAL Overall length
182.8 mm
WT Weight of item
5.7 kg
