Главная Каталог продукции Toolunited 10 401-01 - Converter, rotationally symmetric DIN6987140T12X50

DIN6987140T12X50

DIN6987140T12X50 DIN6987140T12X50 DIN6987140T12X50 DIN6987140T12X50

DIN6987140T12X50

Ingersoll
Артикул: 2927926
В наличии
В корзину
Описание
Характеристики
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
SAI
CCUWS Connection code unit base
0
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
IL - Ingersoll
CXSC Coolant exit style code
0 - Without coolant exit
CZCWS Connection size code
0120
DCP Data chip provision
0 - Without data chip
Delivery state
LL - Stock limited
DF Flange diameter
18.3 mm
DIN
SKG04001085
FamilyProducts
DIN 69871-A40 Adaption
HAND Cutting direction
R - Right
ID Technical product number
2927926
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SAI Screw mounting ISCAR
LOC-01 CCUWS Connection code unit base
0 Metric
LOC-01 CZCWS Connection size code
0120
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SAI01200105
LOC-03 CCFMS Connection code form
10
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0400
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG04001085
LPR Protruding length
50 mm
Name Identifying order number
DIN6987140T12X50
OAL Overall length
118.4 mm
WT Weight of item
0.898 kg
