Главная Каталог продукции Toolunited 10 401-01 - Converter, rotationally symmetric C5-391.5867-20103

C5-391.5867-20103

C5-391.5867-20103 C5-391.5867-20103 C5-391.5867-20103 C5-391.5867-20103

C5-391.5867-20103

Seco
Артикул: 02926960
В наличии
В корзину
Описание
Характеристики
BD Body diameter
33.7 mm
BLQ Balance quality code
PB
CCFWS Connection code form
16
CCSWS Connection code style
5
CCTWS Connection code type
SZD
CCUWS Connection code unit base
8
COMPC Company code
SO - SECO Tools
CZCWS Connection size code
0200
DCP Data chip provision
0 - Without data chip
Delivery state valid from
3/14/2020
DIN
CCS05000185
DLN Diameter lock nut
35 mm
FamilyProducts
C5-391.5867-20103
HAND Cutting direction
N - Neutral
ID Technical product number
02926960
Interface codes
J6 / J61
ISO
CCS01C0500$$$$
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
35.3 mm
LOC-01 CCFWS Connection code form
16
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SZD Collet adapter DIN / ISO
LOC-01 CCUWS Connection code unit base
8 non-dimensional size
LOC-01 CZCWS Connection size code
0200
LOC-01 ISO
SZD16C0200$$$$
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SZD02001685
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
CCS Coromant Capto System SANDVIK
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0500
LOC-03 ISO
CCS01C0500$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
CCS05000185
LPR Protruding length
97.7 mm
Name Identifying order number
C5-391.5867-20103
OAL Overall length
127.7 mm
WT Weight of item
0.9 kg
