Главная Каталог продукции Toolunited 10 401-01 - Converter, rotationally symmetric AB001.K40-B38-061

AB001.K40-B38-061

Артикул: 7604780

В наличии

В корзину

Описание

Характеристики

BD Body diameter

95.25 mm

CCFWS Form

CCSWS Style

CCTWS Type

FDA

CCUWS Unit base

CNSC Coolant entry style code

7 - Coolant entry, decentral and axially concentric

COMPC Company code

W - Walter

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

CZCWS Size code

1500

DCONWS Diameter

38.1 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2023

DF Flange diameter

63.5 mm

DIN

SKG04003795

FamilyProducts

ASME B5.50 shell end milling cutter arbor AB001.K

ID Technical product number

7604780

Interface codes

J6 / J61

ISO

SKG37C0400$$$$

ISYC Subclass

401-01 - Converter, rotationally symmetric

KAP Kappa

0 Degree

LB Body length 1

41.91 mm

LF Functional length

60.96 mm

LOC-01 CCFWS Form

LOC-01 CCSWS Style

0 Hole in machine direction or shaft in workpiece direction

LOC-01 CCTWS Type

FDA Milling arbor mounting

LOC-01 CCUWS Unit base

3 Inch with coolant

LOC-01 CZCWS Size code

1500

LOC-01 DCONWS Diameter

38.1 mm

LOC-01 ISO

FDA12S1500****

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

FDA15001230

LOC-02 CCFWS Form

LOC-02 CCSWS Style

0 Hole in machine direction or shaft in workpiece direction

LOC-02 CCTWS Type

FDA Milling arbor mounting

LOC-02 CCUWS Unit base

3 Inch with coolant

LOC-02 CZCWS Size code

1500

LOC-02 DCONWS Diameter

38.1 mm

LOC-02 ISO

FDA22S1500****

LOC-02-Connection-codes

J4 / J431 - Workpiece end

LOC-02-DIN

FDA15002230

LOC-03 CCFMS Form

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

SKG steep taper shank

LOC-03 CCUMS Unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Size code

0400

LOC-03 DCONMS Diameter

38.1 mm

LOC-03 ISO

SKG37C0400$$$$

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SKG04003795

LPR Protruding length

84.76 mm

LS Shank length

23.8 mm

Name Identifying order number

AB001.K40-B38-061

OAL Overall length

153.06 mm

RPMX Rotational speed maximum

8000 1/min

STDLET Standard letter to the standard number

STDNO Standard

ASME B5.50

THSZMS Connection thread nominal size machine side

5/8"-11

WT Weight of item

2.8 kg
