Главная Каталог продукции Toolunited 10 401-01 - Converter, rotationally symmetric A171.7.100.100.16.HSK

A171.7.100.100.16.HSK

Артикул: 5007145

В наличии

В корзину

Описание

Характеристики

BD Body diameter

48 mm

CCFWS Form

CCSWS Style

CCTWS Type

ZYL

CCUWS Unit base

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

W - Walter

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

CZCWS Size code

0629

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2023

DIN

HSK10000185

FamilyProducts

Whistle notch adaptor A171...HSK

ID Technical product number

5007145

Interface codes

J6 / J61

ISO

HSK01C1000$$$$

ISYC Subclass

401-01 - Converter, rotationally symmetric

KAP Kappa

0 Degree

LB Body length 1

71 mm

LF Functional length

100 mm

LOC-01 CCFWS Form

LOC-01 CCSWS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Type

ZYL cylindrical shank

LOC-01 CCUWS Unit base

2 Inch

LOC-01 CZCWS Size code

0629

LOC-01 ISO

ZYL18R6299****

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

ZYL06291825

LOC-02 CCFWS Form

LOC-02 CCSWS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-02 CCTWS Type

ZYL cylindrical shank

LOC-02 CCUWS Unit base

2 Inch

LOC-02 CZCWS Size code

0629

LOC-02 ISO

ZYL13G1600****

LOC-02-Connection-codes

J4 / J431 - Workpiece end

LOC-02-DIN

ZYL01601305

LOC-03 CCFMS Form

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

HSK Hollow taper shank

LOC-03 CCUMS Unit base

8 non-dimensional size

LOC-03 CZCMS Size code

1000

LOC-03 DCONMS Diameter

100 mm

LOC-03 ISO

HSK01C1000$$$$

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

HSK10000185

LPR Protruding length

100 mm

Name Identifying order number

A171.7.100.100.16.HSK

OAL Overall length

150 mm

RPMX Rotational speed maximum

30000 1/min

STDLET Standard letter to the standard number

STDNO Standard

ISO12164-1

WT Weight of item

2.97 kg
