Главная Каталог продукции Toolunited 10 401-01 - Converter, rotationally symmetric 28003756

28003756

28003756

28003756

Schunk
Артикул: 28003756
В наличии
В корзину
Описание
Характеристики
BD Body diameter
36.5 mm
BD Body diameter 2
70 mm
BHTA Body half taper angle 2
35 Degree
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
SJ - Schunk
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0120
DAH Diameter access hole
11 mm
DBHC Diameter bolt hole circle
95 mm
DCINTF Interference cutting diameter
21.5 mm
DCONWS Diameter
12 mm
DCP Data chip provision
0 - Without data chip
Delivery state
LH - Stocked
DF Flange diameter
120 mm
FamilyProducts
TENDO WZS FLANGE Ø12x111
HAND Cutting direction
N - Neutral
Interface codes
/
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
41 mm
LB Length 2
32 mm
LF Functional length
0 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0120
LOC-01 DCONWS Diameter
12 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL01200115
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
3 Hole pattern (through bore) machine side or hole pattern (threaded hole) machine side or
LOC-03 CCTMS Connection code type
FLx
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LPR Protruding length
111 mm
LSCX Clamping length maximum
111 mm
Name Identifying order number
28003756
NOH Mounting hole count
4
OAL Overall length
111 mm
TA Taper angle
25 Degree
