Главная Каталог продукции Toolunited 10 401-01 - Converter, rotationally symmetric 204216

204216

204216

Schunk

Артикул: 204216

В наличии

В корзину

Описание

Характеристики

BD Body diameter

49.5 mm

CCFWS Connection code form

01

CCSWS Connection code style

5

CCTWS Connection code type

ZYL

CCUWS Connection code unit base

1

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

SJ - Schunk

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

CZCWS Connection size code

0200

DCINTF Interference cutting diameter

34 mm

DCONWS Diameter

20 mm

DCP Data chip provision

0 - Without data chip

Delivery state

LH - Stocked

DF Flange diameter

63.55 mm

DIN

SKG04001795

FamilyProducts

TENDO ES SK40 Ø20x24.6

HAND Cutting direction

N - Neutral

Interface codes

J6 /

ISYC Subclass

401-01 - Converter, rotationally symmetric

LB Body length 1

5.5 mm

LF Functional length

27.9 mm

LOC-01 CCFWS Connection code form

01

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

ZYL cylindrical shank

LOC-01 CCUWS Connection code unit base

1 Metric with coolant

LOC-01 CZCWS Connection size code

0200

LOC-01 DCONWS Diameter

20 mm

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

ZYL02000115

LOC-03 CCFMS Connection code form

17

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

SKG steep taper shank

LOC-03 CCUMS Connection code unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Connection size code

0400

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SKG04001795

LPR Protruding length

24.6 mm

LSCX Clamping length maximum

52.5 mm

Name Identifying order number

204216

TA Taper angle

76 Degree

WT Weight of item

0.7 kg
