Главная Каталог продукции Toolunited 10 401-01 - Converter, rotationally symmetric 201833

201833

201833

Schunk

Артикул: 201833

В наличии

В корзину

Описание

Характеристики

A1 CHA Chamfer angle at length 1

30 Degree

A1 CHW Chamfer width at length 1

2.6 mm

BD Body diameter

30 mm

BD Body diameter 2

40 mm

BHTA Body half taper angle 2

70 Degree

CCFWS Connection code form

01

CCSWS Connection code style

5

CCTWS Connection code type

ZYL

CCUWS Connection code unit base

1

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

SJ - Schunk

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

CZCWS Connection size code

0100

DCINTF Interference cutting diameter

26 mm

DCONWS Diameter

10 mm

DCP Data chip provision

0 - Without data chip

Delivery state

LH - Stocked

DF Flange diameter

40 mm

DIN

CCS04000195

FamilyProducts

TENDO P SCapto C4 Ø10x76

HAND Cutting direction

N - Neutral

Interface codes

J6 /

ISYC Subclass

401-01 - Converter, rotationally symmetric

LB Body length 1

41 mm

LF Functional length

35 mm

LOC-01 CCFWS Connection code form

01

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

ZYL cylindrical shank

LOC-01 CCUWS Connection code unit base

1 Metric with coolant

LOC-01 CZCWS Connection size code

0100

LOC-01 DCONWS Diameter

10 mm

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

ZYL01000115

LOC-03 CCFMS Connection code form

01

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

CCS Coromant Capto System SANDVIK

LOC-03 CCUMS Connection code unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Connection size code

0400

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

CCS04000195

LPR Protruding length

76 mm

LSCN Clamping length minimum

31 mm

LSCX Clamping length maximum

41 mm

Name Identifying order number

201833

TA Taper angle

7.5 Degree

WT Weight of item

0.6 kg
