Главная Каталог продукции Toolunited 10 401-01 - Converter, rotationally symmetric 0204055Z

0204055Z

0204055Z

Schunk

Артикул: 0204055Z

В наличии

В корзину

Описание

Характеристики

A1 CHA Chamfer angle at length 1

30 Degree

A1 CHW Chamfer width at length 1

2.6 mm

BD Body diameter

38 mm

BD Body diameter 2

50 mm

BHTA Body half taper angle 2

70 Degree

CCFWS Connection code form

01

CCSWS Connection code style

5

CCTWS Connection code type

ZYL

CCUWS Connection code unit base

1

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

SJ - Schunk

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

CZCWS Connection size code

0160

DCINTF Interference cutting diameter

34 mm

DCONWS Diameter

16 mm

DCP Data chip provision

0 - Without data chip

Delivery state

LH - Stocked

DF Flange diameter

63 mm

DIN

HSK06300195

FamilyProducts

TENDO Zero HSK-A63 Ø16x90

HAND Cutting direction

N - Neutral

Interface codes

J6 /

ISYC Subclass

401-01 - Converter, rotationally symmetric

LB Body length 1

46 mm

LB Length 2

18 mm

LF Functional length

41 mm

LOC-01 CCFWS Connection code form

01

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

ZYL cylindrical shank

LOC-01 CCUWS Connection code unit base

1 Metric with coolant

LOC-01 CZCWS Connection size code

0160

LOC-01 DCONWS Diameter

16 mm

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

ZYL01600115

LOC-03 CCFMS Connection code form

01

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

HSK Hollow taper shank

LOC-03 CCUMS Connection code unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Connection size code

0630

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

HSK06300195

LPR Protruding length

90 mm

LSCN Clamping length minimum

39 mm

LSCX Clamping length maximum

49 mm

Name Identifying order number

0204055Z

TA Taper angle

7.5 Degree

WT Weight of item

1.2 kg
