Главная Каталог продукции Toolunited 10 401-00 - Adaptive item converter, extender, reducer unspecified Z4MOD08SF165

Z4MOD08SF165

Артикул: 4550373

В наличии

В корзину

Описание

Характеристики

BD Body diameter

27 mm

CCSWS Connection code style

CCUWS Connection code unit base

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

IL - Ingersoll

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCINTF Interference cutting diameter

13 mm

DCP Data chip provision

0 - Without data chip

Delivery state

LL - Stock limited

DIN

ITC04000215

FamilyProducts

Screw-in Type

HAND Cutting direction

R - Right

ID Technical product number

4550373

Interface codes

J6 /

ISYC Subclass

401-00 - Adaptive item converter, extender, reducer unspecified

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCUWS Connection code unit base

1 Metric with coolant

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

IL-K-702

LOC-02-Connection-codes

J4 / J431 - Workpiece end

LOC-02-DIN

MOD00800115

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ITC Ingersoll Tool connection

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0400

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ITC04000215

LPR Protruding length

165 mm

Name Identifying order number

Z4MOD08SF165

OAL Overall length

200 mm

TA Taper angle

3 Degree

WT Weight of item

0.69 kg
