Главная Каталог продукции Toolunited 10 401-00 - Adaptive item converter, extender, reducer unspecified MOD12T08SK025

MOD12T08SK025

Артикул: 2927889

В наличии

В корзину

Описание

Характеристики

BD Body diameter 2

21 mm

CCFWS Connection code form

CCSWS Connection code style

CCTWS Connection code type

SAI

CCUWS Connection code unit base

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

IL - Ingersoll

CXSC Coolant exit style code

0 - Without coolant exit

CZCWS Connection size code

0080

DCP Data chip provision

0 - Without data chip

Delivery state

LH - Stocked

DF Flange diameter

11.7 mm

DIN

IL-K-703

FamilyProducts

Extension for metric thread

HAND Cutting direction

R - Right

ID Technical product number

2927889

Interface codes

J6 /

ISYC Subclass

401-00 - Adaptive item converter, extender, reducer unspecified

LOC-01 CCFWS Connection code form

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

SAI Screw mounting ISCAR

LOC-01 CCUWS Connection code unit base

0 Metric

LOC-01 CZCWS Connection size code

0080

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

SAI00800105

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

IL-K-703

LPR Protruding length

25 mm

Name Identifying order number

MOD12T08SK025

OAL Overall length

47 mm

WT Weight of item

0.04 kg
