Главная Каталог продукции Toolunited 10 401-00 - Adaptive item converter, extender, reducer unspecified MAS403BT50MHD110.140

MAS403BT50MHD110.140

Артикул: 5888039

В наличии

В корзину

Описание

Характеристики

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

IL - Ingersoll

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCP Data chip provision

0 - Without data chip

Delivery state

LA - Soon discontinued

DIN

SKG05005195

FamilyProducts

MAS403BT AD Adaption

HAND Cutting direction

N - Neutral

ID Technical product number

5888039

Interface codes

J6 /

ISYC Subclass

401-00 - Adaptive item converter, extender, reducer unspecified

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

IL-K-1306

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

SKG steep taper shank

LOC-03 CCUMS Connection code unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Connection size code

0500

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SKG05005195

LPR Protruding length

140 mm

Name Identifying order number

MAS403BT50MHD110.140

OAL Overall length

241.8 mm

WT Weight of item

6.8 kg
