Главная Каталог продукции Toolunited 10 401-00 - Adaptive item converter, extender, reducer unspecified HSK A63 B16MN 200

HSK A63 B16MN 200

Артикул: 4561206

В наличии

В корзину

Описание

Характеристики

BD Body diameter

63 mm

BD Body diameter 2

52.8 mm

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

IS - Iscar

CXSC Coolant exit style code

0 - Without coolant exit

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2014

DIN

HSK06300185

FamilyProducts

HSK A 63 B16MN 200

ID Technical product number

4561206

Interface codes

J6 /

ISYC Subclass

401-00 - Adaptive item converter, extender, reducer unspecified

LB Body length 1

155.5 mm

LB Length 2

16.2 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

HSK Hollow taper shank

LOC-03 CCUMS Connection code unit base

8 non-dimensional size

LOC-03 CZCMS Connection size code

0630

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

HSK06300185

LPR Protruding length

200 mm

Name Identifying order number

HSK A63 B16MN 200

WT Weight of item

4.75 kg
