Главная Каталог продукции Toolunited 10 401-00 - Adaptive item converter, extender, reducer unspecified C5-391.5831-08200

C5-391.5831-08200

Артикул: 03049413

В наличии

В корзину

Описание

Характеристики

BD Body diameter

23 mm

BD Body diameter 2

50 mm

BD Body diameter 3

50 mm

BHTA Body half taper angle 2

30 Degree

BLQ Balance quality code

G6.3

COMPC Company code

SO - SECO Tools

CZCWS Connection size code

0080

DCONWS Diameter

8 mm

DCP Data chip provision

1 - With data chip

Delivery state valid from

3/14/2020

DIN

CCS05000185

FamilyProducts

C5-391.5831-08200

HAND Cutting direction

N - Neutral

ID Technical product number

03049413

Interface codes

J6 /

ISYC Subclass

401-00 - Adaptive item converter, extender, reducer unspecified

LB Body length 1

147.25 mm

LF Functional length

163 mm

LOC-01 CZCWS Connection size code

0080

LOC-01 DCONWS Diameter

8 mm

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

CCS Coromant Capto System SANDVIK

LOC-03 CCUMS Connection code unit base

8 non-dimensional size

LOC-03 CZCMS Connection size code

0500

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

CCS05000185

LPR Protruding length

200 mm

Name Identifying order number

C5-391.5831-08200

OAL Overall length

230 mm

TA Taper angle

3 Degree

WT Weight of item

1.5 kg
