Главная Каталог продукции Toolunited 10 401-00 - Adaptive item converter, extender, reducer unspecified C5-391.15-25 075

C5-391.15-25 075

Артикул: 5012460

В наличии

В корзину

Описание

Характеристики

CNSC Coolant entry style code

3 - With Coolant entry, axial concentric and radial

COMPC Company code

W - Walter

CXSC Coolant exit style code

0 - Without coolant exit

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2023

DIN

CCS05000185

FamilyProducts

ER collet chucks C.-391.14

ID Technical product number

5012460

Interface codes

J6 / J61

ISO

CCS01C0500$$$$

ISYC Subclass

401-00 - Adaptive item converter, extender, reducer unspecified

KAP Kappa

0 Degree

LF Functional length

75 mm

LOC-03 CCFMS Form

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

CCS Coromant Capto System SANDVIK

LOC-03 CCUMS Unit base

8 non-dimensional size

LOC-03 CZCMS Size code

0500

LOC-03 DCONMS Diameter

50 mm

LOC-03 ISO

CCS01C0500$$$$

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

CCS05000185

LPR Protruding length

75 mm

LS Shank length

30 mm

Name Identifying order number

C5-391.15-25 075

OAL Overall length

105 mm

STDNO Standard

ISO26623-1

WT Weight of item

1.057 kg
