Главная Каталог продукции Toolunited 10 313-04 - Conical round-(ball-)nose burr 1719.131312

1719.131312

Артикул: 1719.131312

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

12 mm

BMC Body material code

S - Solid steel

BTC Burr type code

CEDCD Cutting edge condition of burrs

CEGC Cutting edge group code

COATN Coating / Покрытие

DIAMANT

COMPC Company code

E - Emuge

DC Cutting diameter

1.3 mm

DCONMSLD Shank diameter lower limit

-0.006 mm

DCONMSUD Shank diameter upper limit

0 mm

Delivery state valid from

10/1/2022

DIN

ZYL00300105

FamilyProducts

Ball Nose Grinding Burr

FHA Flute helix angle

0 Degree

FHH Flute helix hand

N - Hand of helix neutral

FSDCD Burr face design code

GRDMFG Grade manufacturers designation

HSS

GRDPRIO Standard designation of the grade main application

HSSE

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

313-04 - Conical round-(ball-)nose burr

LF Functional length

50 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0030

LOC-03 DCONMS Diameter

3 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00300105

Name Identifying order number

1719.131312

OAL Overall length

50 mm

PRFA Profile included angle

4 Degree

PRFRAD Profile radius 1

0.65 mm

SYMFG Style identifier manufacturers specific

KEL

TCDCONMS ISO-tolerance class shank diameter

Working process

No working processes available
