Главная Каталог продукции Toolunited 10 313-02 - Cylindrical round-(ball-)nose burr 1717.100605

1717.100605

Артикул: 1717.100605

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

2 mm

BMC Body material code

S - Solid steel

BTC Burr type code

CEDCD Cutting edge condition of burrs

CEGC Cutting edge group code

COATN Coating

DIAMANT

COMPC Company code

E - Emuge

DC Cutting diameter

1 mm

DCONMSLD Shank diameter lower limit

-0.008 mm

DCONMSUD Shank diameter upper limit

0 mm

Delivery state valid from

10/1/2022

DIN

ZYL00600105

DN Neck diameter

0.8 mm

FamilyProducts

Ball Nose Grinding Burr

FHA Flute helix angle

0 Degree

FHH Flute helix hand

N - Hand of helix neutral

FSDCD Burr face design code

GRDMFG Grade manufacturers designation

HSS

GRDPRIO Standard designation of the grade main application

HSSE

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

313-02 - Cylindrical round-(ball-)nose burr

LF Functional length

29 mm

LH Head length

12 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0060

LOC-03 DCONMS Diameter

6 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00600105

Name Identifying order number

1717.100605

OAL Overall length

47 mm

PRFRAD Profile radius 1

0.5 mm

SYMFG Style identifier manufacturers specific

WRC

TCDCONMS ISO-tolerance class shank diameter

Working process

No working processes available
