F4152-26.5

Артикул: 5073306

В наличии

В корзину

Описание

Характеристики

BMC Body material code

S - Solid steel

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

W - Walter

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter minimum

26.5 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2023

DIN

MKG00302085

FamilyProducts

HSS machine reamers with Morse taper F4152

FHA Flute helix angle

7 Degree

FHH Flute helix hand

L - Hand of helix left

GRDMFG Grade manufacturers designation

UNBESCHICH

HAND Cutting direction

R - Right

ID Technical product number

5073306

Interface codes

J6 / J61

ISO

MKG20C0030$$$$

ISYC Subclass

311-01 - Solid cylindrical reamer

LF Functional length

183 mm

LOC-03 CCFMS Form

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

MKG Morse taper

LOC-03 CCUMS Unit base

8 non-dimensional size

LOC-03 CZCMS Size code

0030

LOC-03 DCONMS Diameter

3 mm

LOC-03 ISO

MKG20C0030$$$$

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

MKG00302085

LU Usable length

178 mm

Name Identifying order number

F4152-26.5

NOF Flute count

OAL Overall length

277 mm

PLGL Plug length

1.1 mm

RPMX Rotational speed maximum

700 1/min

STDLET Standard letter to the standard number

STDNO Standard

DIN 208

STDSZ Size to the standard number

Working process

REI - Cylindrical reaming

WT Weight of item

0.822 kg
