C32S-QEDR09-42

C32S-QEDR09-42 C32S-QEDR09-42 C32S-QEDR09-42

C32S-QEDR09-42

ZCC Cutting Tools
Артикул: C32S-QEDR09-42
В наличии
В корзину
Описание
Характеристики
CDX Cutting depth maximum
9 mm
CEDC Cutting edge count
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
ZCC - ZCC Cutting Tools
CW Cutting width
2.5 mm
CXSC Coolant exit style code
0 - Without coolant exit
DCP Data chip provision
0 - Without data chip
Delivery state valid from
14.3 kg
DIN
ZYL03202205
DIN CSW1
ZCC-Z ED
DMIN Minimum bore diameter
42 mm
FamilyProducts
Parting & grooving tool holder (internal)
HAND Cutting direction
R - Right
ID Identifying order number
C32S-QEDR09-42
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-05 - Boring bar for ID grooving
LF Functional length
250 mm
LOC-03 CCFMS Form
22
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
0 Metric
LOC-03 CZCMS Size code
0320
LOC-03 DCONMS Diameter
32 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL03202205
OAL Overall length
250 mm
STDDES Standard designation
C32S-QEDR09-42
SX Shank cross section shape code
31 - (left) Round shank
THSC Tool holder shape code
A - offset shank design
WF Functional width
25.3 mm
Working process
DIE - Grooving
