Главная Каталог продукции Toolunited 10 309-01 - Tool holder for longitudinal and transversal turning PTJNR2525M16JET

PTJNR2525M16JET

PTJNR2525M16JET PTJNR2525M16JET PTJNR2525M16JET PTJNR2525M16JET

PTJNR2525M16JET

Seco
Артикул: 02599853
В наличии
В корзину
Описание
Характеристики
A2A Clearance angle major Pos. A
0 Degree
B3A Inscribed circle diameter Pos. A
9.525 mm
BLDA Tool style code Position A
1
C1A Insert thickness Pos. A
4.76 mm
CEDC Cutting edge count
1
COMPC Company code
SO - SECO Tools
D1A Corner radius Pos. A
0.4 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
6/7/2017
DIN
VKT25250105
DIN CSW1
SO-TN2-1604N
EPSR Insert included angle
60 Degree
FamilyProducts
PTJNR2525M16JET
GAMO Rake angle orthogonal
-6 Degree
HAND Cutting direction
R - Right
ID Technical product number
02599853
Interface codes
J6 /
Interface codes CSW1
J41 /
ISISO A Indicator for ISO cutting plate Pos.A
0
ISYC Subclass
309-01 - Tool holder for longitudinal and transversal turning
KAPR Tool cutting edge angle
93 Degree
LAMS Inclination angle
-6 Degree
LF Functional length
150 mm
LH Head length
31 mm
LOC-03 B Shank width
25 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
VKT Square mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
2525
LOC-03 H Shank height
25 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
VKT25250105
MIID Master insert identification
TNGA160404S-01020-L1-C
MTP Clamping type code
P - Hole clamping, with straight bore
Name Identifying order number
PTJNR2525M16JET
OAL Overall length
150 mm
STDDES Standard designation
PTJNR2525M16JET
THSC Tool holder shape code
A - offset shank design
WF Functional width
32 mm
Working process
No working processes available
WT Weight of item
0.8 kg
