Главная Каталог продукции Toolunited 10 309-01 - Tool holder for longitudinal and transversal turning E06M-SCLPR2

E06M-SCLPR2

E06M-SCLPR2

E06M-SCLPR2

Mitsubishi Materials
Артикул: E06M-SCLPR2
В наличии
В корзину
Описание
Характеристики
A2A Clearance angle major Pos. A
7 Degree
BLDA Tool style code Position A
3
CEDC Cutting edge count
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
MI - Mitsubishi Materials
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/1/2022
DIN
ZYL03752215
DMIN Minimum bore diameter
12.1158 mm
FamilyProducts
Coolant Through Carbide Boring Bar, Inch size
GAMF Rake angle radial
15 Degree
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
309-01 - Tool holder for longitudinal and transversal turning
KAPR Tool cutting edge angle
95 Degree
LF Functional length
152.4 mm
LOC-03 CCFMS Connection code form
22
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0375
LOC-03 DCONMS Diameter
0.375 mm
LOC-03 H Shank height
9.144 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL03752215
Name Identifying order number
E06M-SCLPR2
SX Shank cross section shape code
22 - Round shank
THSC Tool holder shape code
A - offset shank design
WF Functional width
6.35 mm
Working process
No working processes available
WT Weight of item
0.31 kg
