Главная Каталог продукции Toolunited 10 308-08 - Full-side angular slot milling cutter R220.49-01.50

R220.49-01.50

R220.49-01.50 R220.49-01.50 R220.49-01.50 R220.49-01.50

R220.49-01.50

SECO Tools
Артикул: 00070079
В наличии
В корзину
Описание
Характеристики
BI Block index
1
CCONMS Connection count machine side
1
CDX Cutting depth maximum
7 mm
CICT Cutting item count
6
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
SO - SECO Tools
CWN Cutting width minimum
7 mm
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
38.1 mm
DCP Data chip provision
0 - Without data chip
DCX Cutting diameter maximum
52 mm
Delivery state valid from
12/1/2023
DHUB Hub diameter
40 mm
DIN
FDA07502220
FamilyProducts
R220.49-01.50
GAMF Rake angle radial
0 Degree
GAMP Rake angle axial
0 Degree
ID Technical product number
00070079
Interface codes
J6 /
ISYC Subclass
308-08 - Full-side angular slot milling cutter
KAPR Tool cutting edge angle
45 Degree
LOC-01 BI Block index
1
LOC-01-Connection-codes
J44 / J441 - Insert (Unknown 01)
LOC-01-DIN
SO-SP12T3 3N
LOC-02 BI Block index
2
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-02-DIN
SO-SP12T3 3N
LOC-03 CCFMS Connection code form
22
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
0750
LOC-03 DCONMS Diameter
19.05 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA07502220
Name Identifying order number
R220.49-01.50
OAL Overall length
40 mm
RPMX Rotational speed maximum
13400 1/min
Working process
No working processes available
WT Weight of item
0.248 kg
ZEFF Face effective cutting edge count
3
ZEFP Peripheral effective cutting edge count
3
