Главная Каталог продукции Toolunited 10 308-06 - Half-side slot milling cutter F2252.B.315.Z20.15.R726

F2252.B.315.Z20.15.R726

F2252.B.315.Z20.15.R726 F2252.B.315.Z20.15.R726 F2252.B.315.Z20.15.R726 F2252.B.315.Z20.15.R726

F2252.B.315.Z20.15.R726

Walter
Артикул: 5159919
В наличии
В корзину
Описание
Характеристики
ADJBY Adjustment property
0 - Adjustment not possible
BMC Body material code
S - Solid steel
CCONMS Connection count machine side
2
CDX Cutting depth maximum
110 mm
CICT Cutting item count
20
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
W - Walter
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
315 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DHUB Hub diameter
90 mm
DIN
FDA06000100
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
20
FamilyProducts
Half side mills F2252
HAND Cutting direction
R - Right
ID Technical product number
5159919
Interface codes
J6 / J61
ISISO A Indicator for ISO cutting plate Pos.A
0
ISO
FDA01G6000$$$$
ISYC Subclass
308-06 - Half-side slot milling cutter
LOC-03 CCFMS Form
01
LOC-03 CCSMS Style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Type
FDA Milling arbor mounting
LOC-03 CCUMS Unit base
0 Metric
LOC-03 CZCMS Size code
0600
LOC-03 DCONMS Diameter
60 mm
LOC-03 ISO
FDA01G6000$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA06000100
MILTTY Mill tool type ISO
E - Disc mill - one side cutting
Name Identifying order number
F2252.B.315.Z20.15.R726
OAL Overall length
19 mm
Working process
FPL - Face milling
WT Weight of item
10.23 kg
ZEFF Face effective cutting edge count
20
ZEFP Peripheral effective cutting edge count
20
