Главная Каталог продукции Toolunited 10 308-06 - Half-side slot milling cutter 335.25-250.2126XL.50-14L

335.25-250.2126XL.50-14L

335.25-250.2126XL.50-14L 335.25-250.2126XL.50-14L 335.25-250.2126XL.50-14L 335.25-250.2126XL.50-14L

335.25-250.2126XL.50-14L

SECO Tools
Артикул: 02814614
В наличии
В корзину
Описание
Характеристики
CCONMS Connection count machine side
1
CDX Cutting depth maximum
88.3 mm
CICT Cutting item count
14
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
SO - SECO Tools
CWN Cutting width minimum
13 mm
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
250 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DHUB Hub diameter
69 mm
DIN
FDA05002100
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
14
FamilyProducts
335.25-250.2126XL.50-14L
GAMF Rake angle radial
-8 Degree
GAMP Rake angle axial
-5 Degree
HAND Cutting direction
N - Neutral
ID Technical product number
02814614
Interface codes
J6 /
ISYC Subclass
308-06 - Half-side slot milling cutter
LOC-03 CCFMS Connection code form
21
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0500
LOC-03 DCONMS Diameter
50 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA05002100
MILTTY Mill tool type ISO
E - Disc mill - one side cutting
Name Identifying order number
335.25-250.2126XL.50-14L
OAL Overall length
32 mm
RPMX Rotational speed maximum
3500 1/min
Working process
No working processes available
WT Weight of item
5.988 kg
ZEFF Face effective cutting edge count
14
ZEFP Peripheral effective cutting edge count
14
