R335.18-200.0810XL.40-14NR4ADJ
R335.18-200.0810XL.40-14NR4ADJ
Артикул:
02723599
В наличии
Характеристики
CCONMS Connection count machine side
1
CDX Cutting depth maximum
53.5 mm
CICT Cutting item count
21
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
SO - SECO Tools
CWN Cutting width minimum
8 mm
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
200 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DHUB Hub diameter
90 mm
DIN
SPK04000100
FamilyProducts
R335.18-200.0810XL.40-14NR4ADJ
GAMF Rake angle radial
1 Degree
GAMP Rake angle axial
0 Degree
HAND Cutting direction
R - Right
ID Technical product number
02723599
Interface codes
J6 /
ISYC Subclass
308-05 - Full-side slot milling cutter
LOC-02 BI Block index
2
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-02-DIN
SO-RD0803 3N
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
SPK Spindle nose mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0400
LOC-03 DCONMS Diameter
40 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SPK04000100
Name Identifying order number
R335.18-200.0810XL.40-14NR4ADJ
OAL Overall length
50 mm
RPMX Rotational speed maximum
6700 1/min
Working process
No working processes available
WT Weight of item
3.142 kg
ZEFF Face effective cutting edge count
7
ZEFP Peripheral effective cutting edge count
7
