F4153.UB31.102.Z05.06
F4153.UB31.102.Z05.06
Артикул:
5517132
В наличии
Характеристики
BI Block index
1
BMC Body material code
S - Solid steel
CCONMS Connection count machine side
2
CDX Cutting depth maximum
24 mm
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
W - Walter
CXSC Coolant exit style code
0 - Without coolant exit
DAH Diameter access hole
26 mm
DC Cutting diameter
101.6 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DHUB Hub diameter
50.8 mm
DIN
FDA25001220
FamilyProducts
Slotting cutters for ?slot milling F4153
HAND Cutting direction
N - Neutral
ID Technical product number
5517132
Interface codes
J6 / J61
ISO
FDA12S1250$$$$
ISYC Subclass
308-05 - Full-side slot milling cutter
LOC-01 BI Block index
1
LOC-01 ISO
WR$$LN0803043N***04
LOC-01-Connection-codes
J44 / J441 - Insert (Unknown 01)
LOC-01-DIN
W-LN0803**
LOC-03 CCFMS Form
12
LOC-03 CCSMS Style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Type
FDA Milling arbor mounting
LOC-03 CCUMS Unit base
2 Inch
LOC-03 CZCMS Size code
1250
LOC-03 DCONMS Diameter
31.75 mm
LOC-03 ISO
FDA12S1250$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA25001220
Name Identifying order number
F4153.UB31.102.Z05.06
OAL Overall length
12 mm
RPMX Rotational speed maximum
9800 1/min
Working process
No working processes available
WT Weight of item
0.38 kg
ZEFF Face effective cutting edge count
5
ZEFP Peripheral effective cutting edge count
5
