Главная Каталог продукции Toolunited 10 308-02 - Shoulder milling cutter SPM D160-12-40R-CA

SPM D160-12-40R-CA

Артикул: 3106909

В наличии

В корзину

Описание

Характеристики

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CICT Cutting item count

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

IS - Iscar

CXSC Coolant exit style code

2 - With Coolant exit, radial

DC Cutting diameter

162 mm

DCP Data chip provision

0 - Without data chip

DHUB Hub diameter

160 mm

DIN

FDA04000215

F23 Number of mounting layers

F24 Cutting item count per mounting layer

FamilyProducts

Face Mills with Adjustable Cartridges for High Speed Machining of Aluminum Alloys, Cast Iron and Carbon Fiber

HAND Cutting direction

R - Right

ID Technical product number

3106909

Interface codes

J6 / J61

ISO

FDA02G4000H$07

ISYC Subclass

308-02 - Shoulder milling cutter

KAPR Tool cutting edge angle

90 Degree

LOC-03 CCTMS Connection code type

FDA Milling arbor mounting

LOC-03 CZCMS Connection size code

0400

LOC-03 DCONMS Diameter

40 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

H$07

LOC-03 ISO

FDA02G4000H$07

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

FDA04000215

Name Identifying order number

SPM D160-12-40R-CA

OAL Overall length

50 mm

RMPX Ramping angle maximum

0 Degree

RPMX Rotational speed maximum

24500 1/min

TCDCONMS ISO-tolerance class shank diameter

Working process

No working processes available

WT Weight of item

2.69 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
