Главная Каталог продукции Toolunited 10 308-01 - Face milling cutter 7802000

7802000

7802000

OSG

Артикул: 7802000

В наличии

В корзину

Описание

Характеристики

A1A Cutting edge angle major Pos. A

90 Degree

A2A Clearance angle major Pos. A

0 Degree

ADJBY Adjustment property

0 - Adjustment not possible

B1A Cutting edge length Pos. A

15.88 mm

B3A Inscribed circle diameter Pos. A

15.88 mm

BLDA Tool style code Position A

2

BMC Body material code

S - Solid steel

C1A Insert thickness Pos. A

7.18 mm

CCONMS Connection count machine side

1

CDX Cutting depth maximum

6.5 mm

CICT Cutting item count

4

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

OSG

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

D4A Cutting edge angle major Pos. A

45 Degree

D6A Wiper edge length Pos. A

3.65 mm

DC Cutting diameter

50 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

65 mm

DHUB Hub diameter

45 mm

DIN

FDA02202210

F23 Number of mounting layers

1

F24 Cutting item count per mounting layer

4

FamilyProducts

OSG PAS PAS15R050M22-4

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

308-01 - Face milling cutter

KAPR Tool cutting edge angle

45 Degree

LOC-03 CCFMS Connection code form

22

LOC-03 CCSMS Connection code style

0 Hole in machine direction or shaft in workpiece direction

LOC-03 CCTMS Connection code type

FDA Milling arbor mounting

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0220

LOC-03 DCONMS Diameter

22 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

H$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

FDA02202210

MTP Clamping type code

M - Top and hole clamping, with cylindrical bore

Name Identifying order number

7802000

OAL Overall length

45 mm

TCDCONMS ISO-tolerance class shank diameter

H6

THUB hub thickness

10 mm

Working process

No working processes available

WT Weight of item

0.41 kg

ZEFF Face effective cutting edge count

4

ZEFP Peripheral effective cutting edge count

4
