Главная Каталог продукции Toolunited 10 307-11 - Straight ball-nosed end mill R218.20-2525.3-22.060A

R218.20-2525.3-22.060A

R218.20-2525.3-22.060A R218.20-2525.3-22.060A R218.20-2525.3-22.060A

R218.20-2525.3-22.060A

SECO Tools
Артикул: 00038464
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
22 mm
BI Block index
1
CCONMS Connection count machine side
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
SO - SECO Tools
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter
25 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DIN
ZYL02501015
FamilyProducts
R218.20-2525.3-22.060A
GAMF Rake angle radial
0 Degree
GAMP Rake angle axial
0 Degree
HAND Cutting direction
R - Right
ID Technical product number
00038464
Interface codes
J6 /
ISYC Subclass
307-11 - Straight ball-nosed end mill
KAPR Tool cutting edge angle
90 Degree
LOC-01 BI Block index
1
LOC-01-Connection-codes
J44 / J441 - Insert (Unknown 01)
LOC-01-DIN
SO-218 20125$
LOC-02 BI Block index
2
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-02-DIN
SO-218 20125$
LOC-03 CCFMS Connection code form
10
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0250
LOC-03 DCONMS Diameter
25 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02501015
LPR Protruding length
60 mm
LS Shank length
60 mm
LU Usable length
56 mm
MILTTY Mill tool type ISO
L - Face and side end mill with ball nose (more then one indexable insert pro cutting edge) 90°
Name Identifying order number
R218.20-2525.3-22.060A
OAL Overall length
116 mm
RPMX Rotational speed maximum
16900 1/min
Working process
No working processes available
WT Weight of item
0.376 kg
ZEFP Peripheral effective cutting edge count
2
