Главная Каталог продукции Toolunited 10 307-07 - Non-centre cutting multiple rows end mill FIN LNK D063-130-4-INT50

FIN LNK D063-130-4-INT50

Артикул: 3106182

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

130 mm

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CICT Cutting item count

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

IS - Iscar

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DC Cutting diameter

63 mm

DCP Data chip provision

0 - Without data chip

DIN

SKG09751195

FamilyProducts

Extended Flute Endmills with Tangentially Clamped Inserts and DIN69871 Shanks for Semi-Finishing Long Shoulders

HAND Cutting direction

R - Right

ID Technical product number

3106182

Interface codes

J6 / J61

ISO

SKG11C0975$$$$

ISYC Subclass

307-07 - Non-centre cutting multiple rows end mill

KAPR Tool cutting edge angle

90 Degree

LH Head length

157 mm

LOC-02 BI Block index

LOC-02 MIID Master insert identification

FIN LNAT 1607 PN-R

LOC-02 ISO

IS$$38693594213027

LOC-02-Connection-codes

J44 / J441 - Insert (Unknown 02)

LOC-02-DIN

IS-38693594213027

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

SKG steep taper shank

LOC-03 CCUMS Connection code unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Connection size code

0975

LOC-03 ISO

SKG11C0975$$$$

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SKG09751195

Name Identifying order number

FIN LNK D063-130-4-INT50

OAL Overall length

277.85 mm

RMPX Ramping angle maximum

0 Degree

Working process

No working processes available

WT Weight of item

5.21 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
