Главная Каталог продукции Toolunited 10 307-07 - Non-centre cutting multiple rows end mill 7802902

7802902

7802902

OSG

Артикул: 7802902

В наличии

В корзину

Описание

Характеристики

A2A Clearance angle major Pos. A

15 Degree

A2B Clearance angle major Pos. B

15 Degree

APMX Depth of cut maximum

45.5 mm

B1A Cutting edge length Pos. A

10 mm

B1B Cutting edge length Pos. B

10 mm

B3A Inscribed circle diameter Pos. A

6.8 mm

B3B Inscribed circle diameter Pos. B

6.8 mm

BLDA Tool style code Position A

99

BLDB Tool style code Position B

99

BMC Body material code

S - Solid steel

C1A Insert thickness Pos. A

3.8 mm

C1B Insert thickness Pos. B

3.8 mm

CCONMS Connection count machine side

1

CICT Cutting item count

13

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

OSG

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

D1A Corner radius Pos. A

0.8 mm

D1B Corner radius Pos. B

0.8 mm

DC Cutting diameter

32 mm

DCP Data chip provision

0 - Without data chip

DIN

ZYL03200115

FamilyProducts

OSG PSEL SS PSEL11R032SS32-3-45

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

307-07 - Non-centre cutting multiple rows end mill

KAPR Tool cutting edge angle

90 Degree

LF Functional length

140 mm

LOC-02 BI Block index

2

LOC-02 MIID Master insert identification

ZDKT11T304SR-GL

LOC-02 MTP Clamping type code 1st step

M Top and hole clamping, with cylindrical hole

LOC-02-Connection-codes

J44 / J441 - Insert (Unknown 02)

LOC-02-DIN

OSG-PSE01

LOC-03 CCFMS Connection code form

01

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0320

LOC-03 DCONMS Diameter

32 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL03200115

LPR Protruding length

80 mm

LS Shank length

80 mm

LU Usable length

60 mm

MTP Clamping type code

M - Top and hole clamping, with cylindrical bore

Name Identifying order number

7802902

OAL Overall length

140 mm

TCDCONMS ISO-tolerance class shank diameter

h6

Working process

No working processes available

WT Weight of item

0.7 kg

ZEFF Face effective cutting edge count

3

ZEFP Peripheral effective cutting edge count

3
