Главная Каталог продукции Toolunited 10 307-05 - Single row rounded end mill 7801705

7801705

Артикул: 7801705

В наличии

В корзину

Описание

Характеристики

A2A Clearance angle major Pos. A

11 Degree

APMX Depth of cut maximum

6 mm

B3A Inscribed circle diameter Pos. A

12 mm

BLDA Tool style code Position A

BMC Body material code

S - Solid steel

C1A Insert thickness Pos. A

4.76 mm

CCONMS Connection count machine side

CICT Cutting item count

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

OSG

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DC Cutting diameter

18 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

30 mm

DIN

SAO01600295

F23 Number of mounting layers

F24 Cutting item count per mounting layer

FamilyProducts

OSG PRC SF PRC12R030SF16-2

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

307-05 - Single row rounded end mill

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

SAO Screw mounting OSG

LOC-03 CCUMS Connection code unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Connection size code

0160

LOC-03 DCONMS Diameter

17 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SAO01600295

LPR Protruding length

40 mm

LU Usable length

18 mm

MTP Clamping type code

M - Top and hole clamping, with cylindrical bore

Name Identifying order number

7801705

OAL Overall length

63 mm

TCDCONMS ISO-tolerance class shank diameter

THSZMS Connection thread nominal size machine side

M16

Working process

No working processes available

WT Weight of item

0.16 kg

ZEFF Face effective cutting edge count
