Главная Каталог продукции Toolunited 10 307-05 - Single row rounded end mill 7800300

7800300

Артикул: 7800300

В наличии

В корзину

Описание

Характеристики

A2A Clearance angle major Pos. A

11 Degree

APMX Depth of cut maximum

5 mm

B3A Inscribed circle diameter Pos. A

10 mm

BLDA Tool style code Position A

BMC Body material code

S - Solid steel

C1A Insert thickness Pos. A

3.97 mm

CCONMS Connection count machine side

CICT Cutting item count

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

OSG

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DC Cutting diameter

10 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

20 mm

DIN

ZYL02000115

F23 Number of mounting layers

F24 Cutting item count per mounting layer

FamilyProducts

OSG PRC SS PRC10R020SS20-2S

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

307-05 - Single row rounded end mill

LF Functional length

130 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0200

LOC-03 DCONMS Diameter

20 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL02000115

LPR Protruding length

80 mm

LS Shank length

80 mm

LU Usable length

15 mm

MTP Clamping type code

M - Top and hole clamping, with cylindrical bore

Name Identifying order number

7800300

OAL Overall length

130 mm

TCDCONMS ISO-tolerance class shank diameter

Working process

No working processes available

WT Weight of item

0.27 kg

ZEFF Face effective cutting edge count
