Главная Каталог продукции Toolunited 10 307-02 - Non-centre cutting single row V-groove end mill 216548 6

216548 6

216548 6 216548 6 216548 6

216548 6

Hoffmann Group
Артикул: 216548 6
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
60 Degree
A2A Clearance angle major Pos. A
7 Degree
APMX Depth of cut maximum
8.5 mm
BD Body diameter
31 mm
BLDA Tool style code Position A
1
CCONMS Connection count machine side
1
CICT Cutting item count
2
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
HOG - Hoffmann Group
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
DC Cutting diameter
32 mm
DCP Data chip provision
0 - Without data chip
DCX Cutting diameter maximum
6 mm
DIN
ZYL02501015
DN Neck diameter
25 mm
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
2
FamilyProducts
Chamfer mill 30°
GAMF Rake angle radial
0 Degree
GAMP Rake angle axial
0 Degree
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
307-02 - Non-centre cutting single row V-groove end mill
KAPR Tool cutting edge angle
60 Degree
LH Head length
38 mm
LOC-03 CCFMS Connection code form
10
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0250
LOC-03 DCONMS Diameter
25 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02501015
LPR Protruding length
53 mm
LS Shank length
57 mm
LU Usable length
8.5 mm
Name Identifying order number
216548 6
OAL Overall length
100 mm
Working process
No working processes available
WT Weight of item
0.38 kg
ZEFF Face effective cutting edge count
2
ZEFP Peripheral effective cutting edge count
2
