Главная Каталог продукции Toolunited 10 307-02 - Non-centre cutting single row V-groove end mill 214911 25/5

214911 25/5

214911 25/5 214911 25/5 214911 25/5

214911 25/5

Hoffmann Group
Артикул: 214911 25/5
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
90 Degree
A2A Clearance angle major Pos. A
17 Degree
APMX Depth of cut maximum
5 mm
AZ Plunge depth maximum
0 mm
B3A Inscribed circle diameter Pos. A
8 mm
BD Body diameter
32.5 mm
BLDA Tool style code Position A
2
C1A Insert thickness Pos. A
3.64 mm
CCONMS Connection count machine side
1
CICT Cutting item count
5
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
HOG - Hoffmann Group
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
D1A Corner radius Pos. A
0.4 mm
DC Cutting diameter
25 mm
DCP Data chip provision
0 - Without data chip
DCX Cutting diameter maximum
35.2 mm
DIN
ZYL02501015
DN Neck diameter
23.2 mm
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
5
FamilyProducts
Softcut HSI indexable chamfer mill..
GAMF Rake angle radial
6 Degree
GAMP Rake angle axial
-6 Degree
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
307-02 - Non-centre cutting single row V-groove end mill
KAPR Tool cutting edge angle
45 Degree
LH Head length
45 mm
LOC-03 CCFMS Connection code form
10
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0250
LOC-03 DCONMS Diameter
25 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02501015
LPR Protruding length
50 mm
LS Shank length
85 mm
LU Usable length
5 mm
Name Identifying order number
214911 25/5
OAL Overall length
130 mm
RMPX Ramping angle maximum
0 Degree
Working process
No working processes available
WT Weight of item
0.44 kg
ZEFF Face effective cutting edge count
5
ZEFP Peripheral effective cutting edge count
5
