Главная Каталог продукции Toolunited 10 307-01 - Non-centre cutting single row end mill 7800017

7800017

7800017

OSG

Артикул: 7800017

В наличии

В корзину

Описание

Характеристики

A2A Clearance angle major Pos. A

15 Degree

APMX Depth of cut maximum

20 mm

B1A Cutting edge length Pos. A

24.18 mm

B3A Inscribed circle diameter Pos. A

16 mm

BLDA Tool style code Position A

99

BMC Body material code

S - Solid steel

C1A Insert thickness Pos. A

6.35 mm

CCONMS Connection count machine side

1

CICT Cutting item count

3

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

OSG

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

30 mm

DCP Data chip provision

0 - Without data chip

DIN

ZYL20002325

DN Neck diameter

48.5 mm

F23 Number of mounting layers

1

F24 Cutting item count per mounting layer

3

FamilyProducts

PDR20R050CN50,8-3L

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

307-01 - Non-centre cutting single row end mill

KAPR Tool cutting edge angle

90 Degree

LOC-03 CCFMS Connection code form

23

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

2 Inch

LOC-03 CZCMS Connection size code

2000

LOC-03 DCONMS Diameter

50.8 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL20002325

LPR Protruding length

170 mm

LS Shank length

85 mm

LU Usable length

40 mm

MTP Clamping type code

M - Top and hole clamping, with cylindrical bore

Name Identifying order number

7800017

OAL Overall length

250 mm

RE Corner radius insert position A

10 mm

TCDCONMS ISO-tolerance class shank diameter

h6

Working process

No working processes available

WT Weight of item

3.5 kg

ZEFF Face effective cutting edge count

3

ZEFP Peripheral effective cutting edge count

3
