Главная Каталог продукции Toolunited 10 303-09 - Thread end mill T1606087

T1606087

Артикул: T1606087

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

4.8 mm

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

Multi-SiC layer

COMPC Company code

OSG

CXSC Coolant exit style code

0 - Without coolant exit

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

9 mm

DIN

ZYL01000105

DN Neck diameter

6.92 mm

FamilyProducts

OSG WH-EM-PNC 9x24 P1.75-INT (M12x1.75) LH

FHH Flute helix hand

L - Hand of helix left

GAMF Rake angle radial

-10 Degree

GRDPRIO Standard designation of the grade main application

HAND Cutting direction

L - Left

Interface codes

J6 /

ISYC Subclass

303-09 - Thread end mill

LN Neck length

28.4 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0100

LOC-03 DCONMS Diameter

10 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01000105

LPR Protruding length

31.7 mm

LS Shank length

48.6 mm

MILTTY Mill tool type ISO

T - Thread cutter

Name Identifying order number

T1606087

OAL Overall length

80 mm

TCDCONMS ISO-tolerance class shank diameter

TD Thread diameter

12 mm

THFT Thread form type

TP Thread pitch

1.75 mm

Working process

No working processes available

ZEFP Peripheral effective cutting edge count
