GFB35706.5510

Артикул: GFB35706.5510

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COATN Coating / Покрытие

TiCN

COMPC Company code

E - Emuge

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

4.45 mm

Delivery state valid from

2/1/2024

DIN

ZYL00600115

FamilyProducts

solid carbide thread milling cutters

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

VHM-TiCN

GRDPRIO Standard designation of the grade main application

VHM

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-09 - Thread end mill

LH Head length

11.305 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0060

LOC-03 DCONMS Diameter

6 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00600115

LPR Protruding length

22 mm

MILTTY Mill tool type ISO

T - Thread cutter

Name Identifying order number

GFB35706.5510

OAL Overall length

58 mm

TDIN Thread diameter nominal inch

5.486 in

THFT Thread form type

UNJF

TP Thread pitch

0.907 mm

TPI Threads per inch

28 1/in

Working process

FSC - Thread milling

WT Weight of item

0.016 kg

ZEFP Peripheral effective cutting edge count
