Главная Каталог продукции Toolunited 10 303-09 - Thread end mill GFB35701.5012

GFB35701.5012

Артикул: GFB35701.5012

В наличии

В корзину

Описание

Характеристики

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

E - Emuge

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

9 mm

Delivery state valid from

2/1/2024

DIN

ZYL01000115

FamilyProducts

solid carbide thread milling cutters

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

VHM

GRDPRIO Standard designation of the grade main application

VHM

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-09 - Thread end mill

LH Head length

22.609 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0100

LOC-03 DCONMS Diameter

10 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01000115

LPR Protruding length

34 mm

MILTTY Mill tool type ISO

T - Thread cutter

Name Identifying order number

GFB35701.5012

OAL Overall length

74 mm

TDIN Thread diameter nominal inch

11.112 in

THFT Thread form type

UNC

TP Thread pitch

1.814 mm

TPI Threads per inch

14 1/in

Working process

FSC - Thread milling

WT Weight of item

0.065 kg

ZEFP Peripheral effective cutting edge count
