Главная Каталог продукции Toolunited 10 303-09 - Thread end mill GF273701.0116

GF273701.0116

Артикул: GF273701.0116

В наличии

В корзину

Описание

Характеристики

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

E - Emuge

CXSC Coolant exit style code

0 - Without coolant exit

DCONMSLD Shank diameter lower limit

-0.011 mm

DCONMSUD Shank diameter upper limit

0 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

13.6 mm

DIN

ZYL01400115

FamilyProducts

thread milling cutter / ZGF

FHH Flute helix hand

N - Hand of helix neutral

FHP Flute helix pitch

0 mm

GAMP Rake angle axial

1 Degree

GRD2ND Standard designation of the grade 2nd application

HSSE

GRD3RD Standard designation of the grade 3rd application

HSSE

GRDMFG Grade manufacturers designation

HSSE

GRDPRIO Standard designation of the grade main application

HSSE

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-09 - Thread end mill

LF Functional length

100 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0140

LOC-03 DCONMS Diameter

14 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01400115

MILTTY Mill tool type ISO

T - Thread cutter

Name Identifying order number

GF273701.0116

OAL Overall length

100 mm

TCDCONMS ISO-tolerance class shank diameter

TD Thread diameter

16 mm

THFT Thread form type

TP Thread pitch

2 mm

Working process

FSC - Thread milling

WT Weight of item

0.17 kg

ZEFP Peripheral effective cutting edge count
