Главная Каталог продукции Toolunited 10 303-09 - Thread end mill GF162211.9661

GF162211.9661

Артикул: GF162211.9661

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

17.145 mm

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

E - Emuge

CXSC Coolant exit style code

0 - Without coolant exit

DCONMSLD Shank diameter lower limit

-0.009 mm

DCONMSUD Shank diameter upper limit

0 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

9.9 mm

DIN

ZYL01001015

FamilyProducts

thread milling cutter / GF

FHA Flute helix angle

29.05 Degree

FHH Flute helix hand

R - Hand of helix right

FHP Flute helix pitch

56 mm

GAMF Rake angle radial

29.05 Degree

GAMP Rake angle axial

1 Degree

GRD2ND Standard designation of the grade 2nd application

HSSE

GRD3RD Standard designation of the grade 3rd application

HSSE

GRDMFG Grade manufacturers designation

HSSE

GRDPRIO Standard designation of the grade main application

HSSE

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-09 - Thread end mill

LH Head length

17.145 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0100

LOC-03 DCONMS Diameter

10 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01001015

LS Shank length

52.855 mm

MILTTY Mill tool type ISO

T - Thread cutter

Name Identifying order number

GF162211.9661

OAL Overall length

70 mm

TCDCONMS ISO-tolerance class shank diameter

THFT Thread form type

TP Thread pitch

1.27 mm

TPI Threads per inch

20 1/in

Working process

FSC - Thread milling

WT Weight of item

0.067 kg

ZEFP Peripheral effective cutting edge count
