Главная Каталог продукции Toolunited 10 303-09 - Thread end mill 3900299

3900299

Артикул: 3900299

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

11.8 mm

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

TiAIN multi-layer

COMPC Company code

OSG

CXSC Coolant exit style code

0 - Without coolant exit

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

5.9 mm

DIN

ZYL00600105

FamilyProducts

OSG WX-PNC D5,9 G28x5,9

FHA Flute helix angle

30 Degree

FHH Flute helix hand

R - Hand of helix right

GAMF Rake angle radial

5 Degree

GRDPRIO Standard designation of the grade main application

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-09 - Thread end mill

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0060

LOC-03 DCONMS Diameter

6 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00600105

LPR Protruding length

20 mm

LS Shank length

48.2 mm

MILTTY Mill tool type ISO

T - Thread cutter

Name Identifying order number

3900299

OAL Overall length

60 mm

TCDCONMS ISO-tolerance class shank diameter

TDFR Thread diameter nominal fraction

1/16 in

THFT Thread form type

TPI Threads per inch

28 1/in

Working process

No working processes available

ZEFP Peripheral effective cutting edge count
