Главная Каталог продукции Toolunited 10 303-06 - Ball-nosed end mill SB207.750P2B.3Z2 TIN

SB207.750P2B.3Z2 TIN

SB207.750P2B.3Z2 TIN SB207.750P2B.3Z2 TIN SB207.750P2B.3Z2 TIN SB207.750P2B.3Z2 TIN

SB207.750P2B.3Z2 TIN

SECO Tools
Артикул: 17008540
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
33.338 mm
COMPC Company code
SO - SECO Tools
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
19.05 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
6/7/2017
DIN
ZYL05001025
FamilyProducts
SB207.750P2B.3Z2 TIN
FHA Flute helix angle
30 Degree
GAMF Rake angle radial
30 Degree
GAMP Rake angle axial
10 Degree
GRDMFG Grade manufacturers designation
TIN
HAND Cutting direction
R - Right
ID Technical product number
17008540
Interface codes
J6 /
ISYC Subclass
303-06 - Ball-nosed end mill
LOC-03 CCFMS Connection code form
10
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
0500
LOC-03 DCONMS Diameter
12.7 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL05001025
LS Shank length
45.24 mm
Name Identifying order number
SB207.750P2B.3Z2 TIN
NameAnsi Identifying order number inch alternative
SB207-0.750-P2-B.3-Z2 TIN
OAL Overall length
84.138 mm
PRFRAD Profile radius 1
9.525 mm
Working process
No working processes available
WT Weight of item
0.1 kg
ZEFP Peripheral effective cutting edge count
2
