EP01950601
EP01950601
Артикул:
EP01950601
В наличии
Характеристики
APMX Depth of cut maximum
1.2 mm
BMC Body material code
H - Solid carbide
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
Multi-SiC
COMPC Company code
OSG
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
1.5 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
10/1/2019
DIN
ZYL00400105
DN Neck diameter
1.45 mm
FamilyProducts
EP01950601
FHA Flute helix angle
30 Degree
FHH Flute helix hand
R - Hand of helix right
GAMF Rake angle radial
2 Degree
GAMP Rake angle axial
6 Degree
GRDPRIO Standard designation of the grade main application
HC
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
303-06 - Ball-nosed end mill
LN Neck length
3 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0040
LOC-03 DCONMS Diameter
4 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00400105
LPR Protruding length
8 mm
LS Shank length
37 mm
Name Identifying order number
EP01950601
OAL Overall length
45 mm
PRFRAD Profile radius 1
0.75 mm
TCDCONMS ISO-tolerance class shank diameter
h6
Working process
No working processes available
ZEFF Face effective cutting edge count
2
ZEFP Peripheral effective cutting edge count
2
ZNC Cutting edge centre count
2
