Главная Каталог продукции Toolunited 10 303-06 - Ball-nosed end mill 2620.150

2620.150

Артикул: 2620.150

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

1.1 mm

BMC Body material code

D - Solid steel with soldered hard-alloy inserts (BN or DP)

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

ohne

COMPC Company code

E - Emuge

CRCLDIN Chip removal class

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

1.5 mm

DCONMSLD Shank diameter lower limit

-0.004 mm

DCONMSUD Shank diameter upper limit

0 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

10/1/2022

DIN

ZYL00400105

DN Neck diameter

1.45 mm

FamilyProducts

Ball Nose End Mill

FHA Flute helix angle

30 Degree

GRDMFG Grade manufacturers designation

CBN

GRDPRIO Standard designation of the grade main application

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-06 - Ball-nosed end mill

LF Functional length

50 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0040

LOC-03 DCONMS Diameter

4 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$04

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00400105

LPR Protruding length

22 mm

LS Shank length

28 mm

MILTTY Mill tool type ISO

L - Face and side end mill with ball nose (more then one indexable insert pro cutting edge) 90°

Name Identifying order number

2620.150

OAL Overall length

50 mm

PRFRAD Profile radius 1

0.75 mm

TCDCONMS ISO-tolerance class shank diameter

Working process

No working processes available

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
