Главная Каталог продукции Toolunited 10 303-06 - Ball-nosed end mill 1867A.010

1867A.010

Артикул: 1867A.010

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

22 mm

COATN Coating

TIALN

COMPC Company code

E - Emuge

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

10 mm

DIN

ZYL01000105

FamilyProducts

Kugelfräser

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

GRDPRIO Standard designation of the grade main application

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-06 - Ball-nosed end mill

LF Functional length

72 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0100

LOC-03 DCONMS Diameter

10 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01000105

LPR Protruding length

32 mm

Name Identifying order number

1867A.010

OAL Overall length

72 mm

PRFRAD Profile radius 1

5 mm

STDLET Standard letter to the standard number

STDNO Standard

DIN 6527

TCDCONMS ISO-tolerance class shank diameter

Working process

FDR - Rotary milling, turn milling,FPR - Profile milling

WT Weight of item

0.001 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
