Главная Каталог продукции Toolunited 10 303-02 - Centre cutting end mill MM16-15911-R08-MD07 T60M

MM16-15911-R08-MD07 T60M

MM16-15911-R08-MD07 T60M MM16-15911-R08-MD07 T60M MM16-15911-R08-MD07 T60M MM16-15911-R08-MD07 T60M

MM16-15911-R08-MD07 T60M

Seco
Артикул: 74034271
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
11 mm
COMPC Company code
SO - SECO Tools
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
15.875 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
3/14/2020
DIN
SMM01600105
F71 Number of corner designs
1
FamilyProducts
MM16-15911-R08-MD07 T60M
FHA Flute helix angle
6 Degree
FHH Flute helix hand
R - Hand of helix right
GAMF Rake angle radial
6 Degree
GAMP Rake angle axial
0 Degree
GRDMFG Grade manufacturers designation
T60M
HAND Cutting direction
R - Right
ID Technical product number
74034271
Interface codes
J6 / J61
ISO
SMM01G1600$$$$
ISYC Subclass
303-02 - Centre cutting end mill
LF Functional length
13.58 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SMM
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0160
LOC-03 ISO
SMM01G1600$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SMM01600105
Name Identifying order number
MM16-15911-R08-MD07 T60M
NameAnsi Identifying order number inch alternative
MM16-0.625-R2-MD07 T60M
RE Corner radius
0.8 mm
Working process
No working processes available
WT Weight of item
0.008 kg
ZEFF Face effective cutting edge count
1
ZEFP Peripheral effective cutting edge count
1
