Главная Каталог продукции Toolunited 10 303-02 - Centre cutting end mill EC-E7 12-02C12R1.5N83CE IS6

EC-E7 12-02C12R1.5N83CE IS6

Артикул: 3318460

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

1.3 mm

BMC Body material code

C - All-ceramics

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

Uncoated

COMPC Company code

IS - Iscar

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

12 mm

DCP Data chip provision

0 - Without data chip

DIN

ZYL01200105

DN Neck diameter

11.5 mm

F71 Number of corner designs

FamilyProducts

3 and 7 Flute Solid Ceramic Endmills with Relieved Necks for Machining Superalloys, Cast Iron and Graphite

FHA Flute helix angle

40 Degree

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

IS6

HAND Cutting direction

R - Right

ID Technical product number

3318460

Interface codes

J6 / J61

ISO

ZYL01G1200h$06

ISYC Subclass

303-02 - Centre cutting end mill

LF Functional length

83 mm

LH Head length

12 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0120

LOC-03 DCONMS Diameter

12 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03 ISO

ZYL01G1200h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01200105

Name Identifying order number

EC-E7 12-02C12R1.5N83CE IS6

OAL Overall length

83 mm

RE Corner radius

1.5 mm

RMPX Ramping angle maximum

3 Degree

TCDCONMS ISO-tolerance class shank diameter

Working process

No working processes available

WT Weight of item

0.03 kg

ZEFP Peripheral effective cutting edge count
