3540L.16500A
3540L.16500A
Артикул:
3540L.16500A
В наличии
Характеристики
APMX Depth of cut maximum
18.5 mm
BMC Body material code
H - Solid carbide
CNSC Coolant entry style code
0 - Without coolant entry
COATN Coating
ALCR
COMPC Company code
E - Emuge
CRCLDIN Chip removal class
N
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
16 mm
DCONMSLD Shank diameter lower limit
-0.011 mm
DCONMSUD Shank diameter upper limit
0 mm
DCP Data chip provision
0 - Without data chip
DCX Cutting diameter maximum
16 mm
Delivery state valid from
10/1/2022
DIN
ZYL01600105
DN Neck diameter
16 mm
FamilyProducts
Circle Segment End Mill
FHA Flute helix angle
30 Degree
FHH Flute helix hand
R - Hand of helix right
GRDMFG Grade manufacturers designation
HM
GRDPRIO Standard designation of the grade main application
HC
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
303-00 - End mill unspecified
LF Functional length
108 mm
LH Head length
18.5 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0160
LOC-03 DCONMS Diameter
16 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01600105
LPR Protruding length
60 mm
LS Shank length
48 mm
MILTTY Mill tool type ISO
G - Side end mill (one or more indexable insert pro cutting edge) 90°
Name Identifying order number
3540L.16500A
OAL Overall length
108 mm
PRFA Profile included angle
40 Degree
PRFRAD Profile radius 1
4 mm
TCDCONMS ISO-tolerance class shank diameter
h6
Working process
No working processes available
ZEFF Face effective cutting edge count
3
ZEFP Peripheral effective cutting edge count
3
