Главная Каталог продукции Toolunited 10 303-00 - End mill unspecified 206266 16

206266 16

Артикул: 206266 16

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

8.8 mm

AZ Plunge depth maximum

0 mm

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

TIALN

COMPC Company code

HOG - Hoffmann Group

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

16 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

6 mm

DIN

ZYL01600105

DN Neck diameter

14.5 mm

FamilyProducts

Solid carbide end torus cutter

FHA Flute helix angle

20 Degree

FHH Flute helix hand

R - Hand of helix right

GAMF Rake angle radial

12 Degree

GAMP Rake angle axial

-5 Degree

GRDMFG Grade manufacturers designation

VHM

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-00 - End mill unspecified

KAPR Tool cutting edge angle

14 Degree

LH Head length

9.5 mm

LN Neck length

35 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0160

LOC-03 DCONMS Diameter

16 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$05

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01600105

LPR Protruding length

40 mm

LS Shank length

60 mm

MILTTY Mill tool type ISO

N - Torus End Mill

Name Identifying order number

206266 16

OAL Overall length

100 mm

RE Corner radius

1.3 mm

RMPX Ramping angle maximum

0 Degree

TCDCONMS ISO-tolerance class shank diameter

Working process

No working processes available

WT Weight of item

0.264 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
